RO-710 | OEM/ODM Customized Logo RO Purifier Water Filter System, 5-Stage 50 75 100GPD NSF Membrane Compact Under Sink Machine with Pump&Tank, White

Item No:RO-710

SHARE:

  • Under-sink type
  • Five stages 10" standard filter cartridges
  • With booster pump/transformer(110V or 220V 24VDC)
  • With shuttle valve
  • Capacity: 50gallons per day
  • Waste water ratio: 1:3
  • Flow rate : 1.5liter/min
  • Applicable Pressure:≦50PSI
  • Please install a pressure reducing valve if the water pressure exceeds 60 PSI.
Dim.
L38xW25xH41 (cm)
Quantity
Min. order>pcs
Request
Feature
  1. Compact box design,the internal structure is 100% made of ABS plastic steel structure, no risk of rust
  2. Tool not required to open front panel, easy to replace filter
  3. In-line filter, R.O. membrane, and storage tank through NSF Certification.
  4. Using the Magnet Wire transformer to ensure stable voltage,
  5. The membrane housing has double O-ring design to ensure durability and no leakage
  6. Powder steel plate coating, it is not easy to rust
  7. Completed set & functional components have been passed 300 PSI (15 minutes)~500 PSI (instantaneous) burst test & 100,000 times cycle test under 150 PSI water pressure(conform to NSF test criteria)
  8. 100% pure raw materials for spare parts contacted water.
  9. Before shipment all pass 100% leaking test
  10. Made in Taiwan

RO SYSTEM SEALED DESIGN

RO SYSTEM NSF CERTIFICATED WATER PARTS

RO SYSTEM ENAMELED WIRE TRANSFORMER

RO SYSTEM WITH DOUBLE SEAL DESIGN

RO SYSTEM WHITE COATED TO PROTECT AGAINST RUST

QUALITY CONTROL

100% PURE RAW MATERIAL INJECTION

BEFORE SHIPMENT ALL PASS 100% LEAKING TEST



ITEMS

RO-700

Cartridge Stages

5 Stages

Booster Pump 50GPD 24VDC
Transformer 100~240V,24V,1.5A
Cartridge Type 9-7/8” Standard filter
Membrane(gallon) NSF

50/75/100GPD (NSF) Optional

Shutoff Valve 1/4"FIP
Less Drain 1:3
Water Output Flow  1.5LPM
PE Tube Size

 1/4"OD(6.35φ m/m)

Fitting Connect

  1/4"JACO&Quick connector

Storage Tank

Metal 4 gallons

Applicable pressure ≤50PSI
Dimensions (w/o tank) L380xW250xH410 (mm)
Weight 10.5KG
Specification
Model No. Fitting Type Weight (incl. tank) Cu'ft
RO-710 JACO 13.5 kgs 2.92 cu.ft.



Cartridges:

Stage Model No. Media Function
1st PP10-05 PP sediment, 5 µ Remove dirt, sand and other sediment
2nd CC-5C  Granular Activated Carbon Redue chlorine
3rd CBC-5CTO Carbon Block Redue chlorine, taste & odor
4th MBS-1050 50 GPD membrane, NSF Remove virus, bacteria, heavy metal, etc.
5th AIC-10 Coconut GAC, NSF Have better tasting of water



ITEMS

RO-700

Cartridge Stages

5 Stages

Booster Pump 50GPD 24VDC
Transformer 100~240V,24V,1.5A
Cartridge Type 9-7/8” Standard filter
Membrane(gallon) NSF

50/75/100GPD (NSF) Optional

Shutoff Valve 1/4"FIP
Less Drain 1:3
Water Output Flow  1.5LPM
PE Tube Size

 1/4"OD(6.35φ m/m)

Fitting Connect

  1/4"JACO&Quick connector

Storage Tank

Metal 4 gallons

Applicable pressure ≤50PSI
Dimensions (w/o tank) L380xW250xH410 (mm)
Weight 10.5KG


Assembly

Spare parts Model No. Spec.
Housing HE1014WW-C 10" White, with 1/4" NPT
Membrane housing HM-256  White, 1/8"NPTx1/8"NPT
Storage tank TANK-4MW (NSF) 4 gallon, metal white
Shut-off valve RO-S001 White, 1/4" Jaco type
Drinking faucet ZWDF-1002 8" tall spout, 3" shank, lead-free
Flow restrictor FRB-450 bead type, 450ml, green color



Accessories

Spare parts Model No. Spec.
Water feed adaptor BV-1414L 1/4" ball valve with 1/2"MIPx1/2"FIP water feed fitting
Wrench HAN-01W Plastic White
PE tube PE-14W-NSF 1/4" tube, white, NSF
Ball valve for tank BV-8P Plastic, 1/4" Jaco


Package

Carton box type Package
Export standard carton box System and tank are packed seperated


Containers

Container Dimension Cu'ft Quantity
20ft 1,172 CU'FT 270PCS
40ft 2,385 CU'FT 540PCS
40'HQ 2,690 CU'FT 620PCS




Others

  • Quick-fitting type system is optional
  • Manual flush valve is optional
