RO Membrane Housing

Item No:HM-253

SHARE:

  1. Double o-ring
  2. 1/8"NPT & 1/4"NPT & 1/4"E-Z  connect cap available
  3. Material: Polypropylene
  4. Weight:313g
Color
Dim.
Quantity
-
+
Min. order>pcs
Request
Feature
  1. 1/8"NPT & 1/4"NPT & 1/4"E-Z  connect cap available
  2. 100% pure raw material injection
  3. PP white housing have been done 100,000times strict cycle test under 150PSI high water pressure. (conform to NSF test criteria)
  4. Made in Taiwan
Specification
Model No. Specification Q'TY/CTN Weight (Kgs) Cu'ft
HM-253(1/8") 1/8"NPT POLYPROPYLENE WHITE CAP, HOUSING LENGTH:327MM,INLET 1/8"NPT (DRAIN &PERMEATE) 35 10.6 2.1
HM-253(1/4") 1/4"NPT POLYPROPYLENE WHITE CAP, HOUSING LENGTH:327MM,INLET 1/8"NPT (DRAIN &PERMEATE) 35 10.6 2.1
HM-253EZ 1/4"E-Z QUICK CONNECT POLYPROPYLENE WHITE CAP, HOUSING LENGTH:327MM,INLET 1/4"E-Z QUICK CONNECT  (DRAIN &PERMEATE) 35 10.6 2.1



Material : P.P. = Polypropylene(White housing)
