RO-808 | OEM/ODM Customized Compact RO Purifier Water Filter System, 5-Stage 50 75 GPD NSF Membrane Counter-top Machine with Tank, LED Device

Item No:RO-808

SHARE:

  • Counter-top RO System with Storage Tank
  • Five stages filter cartridges
  • With pump & transformer (110V or 220V 24VDC)
  • With solenoid valve
  • LED blue light
  • LED filter change reminder with water leak detector
  • With pressure gauge to monitor operation status of system
  • In-line filter, R.O. membrane and storage tank are NSF certified
  • Capacity: 50 GPD or 75GPD
  • Waste water ratio: 1:3
  • Flow rate : 1.5 liters/min
  • Operating pressure: 50PSI
  • Please install a pressure reducing valve if the water pressure exceeds 60 PSI.
Dim.
L58xW23xH42 (cm)
Quantity
Min. order>pcs
Request
Feature
  1. With patented quick- changed 3-stage pre-filter. You can change them without any tools.
  2. ABS material compact casing designed to prevent rusting. Easy to disassemble the casing which also can effectively block mosquitoes and dust
  3. Easy access casing. Safe your time to replacing cartridges
  4. Equipped with drip tray to keep the countertop clean
  5. LED blue light equipped. The water filter can be part of home appliance
  6. LED filter change reminder with water leak detector
  7. Equipped with pressure gauge to monitor operation status easily
  8. Using magnet wired transformer to stabilize voltage, ensure durability and keep from overheating
  9. Membrane housing designed with 2 o-rings to ensure durability and prevent water leak
  10. The system passed 100,000 times cycle test under 150 PSI water pressure
  11. Functional components also passed cycle and burst test which conform to NSF test protocol
  12. Water contact components are produced with all raw materials
  13. 100% leak test before delivery
  14. Made in Taiwan

RO SYSTEM SEALED DESIGN

RO SYSTEM REMOVABLE DRIP TRAY

RO SYSTEM LEAK AND MALFUNCTION DETECTION SYSTEM

RO SYSTEM COOL BLUE-RAY DISPLAY QUITE STYLISH

RO SYSTEM CARTRIDGE CHANGE INDICATOR

RO SYSTEM PRESSURE GAUGE

RO SYSTEM MAGNET WIRE TRANSFORMER

RO SYSTEM WITH DOUBLE SEAL DESIGN

QUALITY CONTROL

100% PURE RAW MATERIAL INJECTION

BEFORE SHIPMENT ALL PASS 100% LEAKING TEST.





ITEMS

RO-808

Cartridge Stages

5 Stages

Booster Pump 50 GPD, 24VDC
Cartridge Type IN-LINE Cartridge
Membrane(gallon) NSF

50 Gallon

Solenoid Valve SOLENOID VALVES White, 1/4" Jaco type
Less Drain 1:3
Water Output Flow  1.5LPM
PE Tube Size

 1/4"OD(6.35φ m/m)

Storage Tank

3.2 Gallon

Applicable water pressure ≤50PSI
Dimensions L 580xW 230xH 420 (mm)
Weight   10 kg
Specification
Model No. PUMP Fitting Type Weight (incl. tank) Cu'ft
RO-808 YES JACO 13kgs 4.35 cu.ft



Cartridges:

Stage Model No. Media Function
1st AIP-12 11" ,PP sediment, 5 µ Remove dirt, sand and other sediment
2nd AIC-12 11" ,Coconut GAC   Reduce chlorine, taste & odor
3rd AIP-12 11" ,PP sediment, 5 µ Remove dirt, sand and other sediment
4th MBS-1050 50 GPD membrane, NSF Remove virus, bacteria, heavy metal, etc.
5th AIC-10 Coconut GAC, NSF Have better tasting of water



ITEMS

RO-808

Cartridge Stages

5 Stages

Booster Pump 50 GPD, 24VDC
Cartridge Type IN-LINE Cartridge
Membrane(gallon) NSF

50 Gallon

Solenoid Valve SOLENOID VALVES White, 1/4" Jaco type
Less Drain 1:3
Water Output Flow  1.5LPM
PE Tube Size

 1/4"OD(6.35φ m/m)

Storage Tank

3.2 Gallon

Applicable water pressure ≤50PSI
Dimensions L 580xW 230xH 420 (mm)
Weight   10 kg



Assembly

Spare parts Model No. Spec.
Membrane housing HM-256  White, 1/8"NPTx1/8"NPT
Storage tank TANK-4MW (NSF) 4 gallon, metal white
SOLENOID VALVES SD22024 White, 1/4" Jaco type
Flow restrictor FRB-450 bead type, 450ml, green color
PUMP PUMP-5024DC 50 GPD, 24VDC
VOLTAGE TRAN-22024DC 100~240/24VDC,1.2A, ROUND PLUG



Accessories

Spare parts Model No. Spec.
Water feed adaptor BV-1414L 1/4" ball valve with 1/2"MIPx1/2"FIP water feed fitting
PE tube PE-14W-NSF 1/4" tube, white, NSF
Ball valve for tank BV-8P Plastic, 1/4" Jaco


Package

Carton box type Package
Export standard carton  box System and tank are packed seperated



Others

■  Quick-fitting type system is optional

Certificates
  Taiwan Small & Medium Enterprises Innovation Award
